Concrete mixer bucket 100 litres
Capacity: 100 litres
item number: SI100
Technical data:
Type | Unit | SI100 |
Recommended capacity | liter | 100 |
Max capacity | liter | 125 |
Weight (empty) | kilogram | 220 |
Weight (full) | kilogram | ca. 450 |
Recommended/max. oil flow | liter/minute | 40/75 |
Continuous/max. pressure | bar | 130/180 |
Transmission | gearbox | |
Draininghose | hydraulic |
Equipment of our concrete mixer buckets
• 100 litres, max. capacity 125 litres
• Weight: approx. 220 kg – Weight with concrete: approx. 450 kg
• Danfoss hydraulic motor OMR 160 with gearbox
• Inner lining of the bucket in HARDOX 450 - thickness: 4 mm
• Auger from HARDOX 500 – thickness: 12 mm
• Safety grid with prongs for opening the cement bags
• 6/2 valve for switching between mixing and hydraulic draining device
• Draininghose, length: 2 m
• 2 pieces hydraulice hose and socket as well as cable set
Optionally available:
• Suitable holder for carrier device
• Gas spring for protective lattice incl. shut-off valve engine (lt. CE NORM)
• Diaphragm accumulator (pressure compensation for various carrier devices)
Dimensions
![None](/media/filer_public_thumbnails/filer_public/bb/4d/bb4de550-8c70-4b32-89d0-5610d12b7deb/si100abmessungen.png__800x0_q85_subsampling-2.jpg)
A | 650 |
B | 700 |
C | 120 |
D | 800 |
F | 1000 |
